HVT Fabricated Venturi Flow Meter (HVT-FV)
+/- 0.50% Uncalibrated Uncertainty
Low Loss, Municipal & Industrial Applications
- Line size: 4 to 96 inches.
- Head loss % of Differential: 3.50 to 10.0 percent
- Recommended pipe Reynolds number: Greater than 75,000 for basic accuracy
- Specifications
Line Size 4 to 96 inches. Larger sizes available upon request. Head loss % of Differential 3.50 to 10.0 percent Basic Accuracy (% of Total) +/- 0.25 (Calibrated) +/- 0.50% (2 Sigma) (Uncalibrated) Recommended pipe Reynolds number Greater than 75,000 Required Straight Piping Consult PFS datasheet Beta Range 0.30 through 0.75 Useful Service Life Very Long Service Functional Limits Clear liquid, gas, contaminated and solid-bearing line fluid Applications WTP Filter Effluent Rate of Flow Control, Special Lay-lengths to fit existing piping constraints, Potable Water, Water Treatment Plant, Wastewater Treatment Plant Common Materials Cast Iron or Ductile Iron body with 304 or 316SS throat - Description
The HVT-Halmi Venturi Flow Element in Cast Iron and Ductile Iron form is offered exclusively by Primary Flow Signal, Inc. for the highest accuracy and reliability for flow measurement of pressurized line fluids, including liquids and gases, as well as high-viscosity line fluids, solids-bearing line fluids, and harsh or contaminated line fluids.
The Cast Iron (HVT-CI) is well proven in municipal water and wastewater flow measurement and control applications, as well as air and other gases.
The Ductile iron (HVT-DI) version is available for higher line pressure applications.
- Documentation
Additional Images, Charts, or Drawings
Support and Service
Our full-time, dedicated service group offers prompt reliable technical support services such as; evaluation, repair and recertification for flow meters including a competitor’s product. Onsite calibration services are performed by our experienced technicians proficient in using the latest test equipment.
If your application requires unique meter and instrumentation features our engineering team will design the appropriate custom equipment.
Our extensive inventory permits rapid shipment, typically within 24 hours, thus minimizing expensive down time.
